Name: Stainless steel ball valve 715XS 2 piece body BSP + ISO pad 1/2''
SKU: 6236
Price: 41.371428571429 EUR
Availability: InStock

Stainless steel ball valve 715XS 2 piece body BSP + ISO pad 1/2''

Stainless steel ball valve 715XS 2 piece body BSP + ISO pad 1/2''

€41.37 (excl. btw)

The 715 XS series is a stainless steel ball valve with ISO pad. Crafted with CF8M body & ball, compliant with 2014/68/EU Directive. RTFE seats, PTFE/FKM stem tightness, full bore, anti-blowout stem, and antistatic device.

In stock Subject prior to sales
Categories : Kogelkranen

Documenten:

Certificate of conformity	Download
Technical datasheet	Download
Technical datasheet FR	Download

Description
Technical Specifications

Specification	Value
Option certificate 3.1	Yes
Shaft/stem matérial	Stainless steel 316
ATEX compatible	Yes
DN	DN15 - 1/2''
Face to Face (mm)	55.0
Body material	Stainless steel CF8M (1.4408)
PS (bar)	63
Connections	BSP FF
TS max (°C)	180
TS min (°C)	-10
Warranty period	1 year
CE	Risk category III

If you have any questions about this product, please feel free to contact us.

Product Name	Product Number	EVAC Number	Price	Add to Cart
6237	BSP FF Stainless steel CF8M (1.4408) DN15 - 1/2''	272402	S1006466	€41.37 (excl. btw)	add to cart
6238	BSP FF Stainless steel CF8M (1.4408) DN20 - 3/4''	272403	S1006467	€48.96 (excl. btw)	add to cart
6239	BSP FF Stainless steel CF8M (1.4408) DN25 - 1''	272404	S1006468	€61.20 (excl. btw)	add to cart
6240	BSP FF Stainless steel CF8M (1.4408) DN32 - 1''1/4	272405	S1006469	€82.74 (excl. btw)	add to cart
6241	BSP FF Stainless steel CF8M (1.4408) DN40 - 1''1/2	272406	S1006470	€117.43 (excl. btw)	add to cart
6242	BSP FF Stainless steel CF8M (1.4408) DN50 - 2''	272407	S1006471	€178.21 (excl. btw)	add to cart
6243	BSP FF Stainless steel CF8M (1.4408) DN65 - 2''1/2	272408	S1006472	€297.01 (excl. btw)	add to cart
6244	BSP FF Stainless steel CF8M (1.4408) DN80 - 3''	272409	S1006473	€428.40 (excl. btw)	add to cart
